Buffered Mult

WMD Buffered Mult: Precision Signal Distribution

The WMD Buffered Mult is an essential utility for any modular setup where signal accuracy is paramount. Unlike passive multiples, this buffered version utilizes active electronics to duplicate a signal without the voltage drop associated with passive splitting. This is critical when sending pitch information (1V/Oct) to multiple oscillators, ensuring your system stays perfectly in tune. With two independent sections, the WMD Buffered Mult provides a reliable, transparent solution for distributing complex CV and audio signals throughout your rack.

Key Features:

• Active Buffering: Eliminates signal loss and "loading effects" when patching to multiple destinations.

• High-Precision Tracking: Perfect for critical CV tasks like pitch distribution and synchronization.

• Dual-Channel Layout: Features two independent input-to-output sections for versatile routing.

• Transparent Audio Path: Low-noise circuitry makes it ideal for splitting audio signals without coloration.

• Space-Efficient: Provides vital utility in a compact 4HP footprint.

Technical Specifications:

• Width: 4HP

• Depth: 25mm

• Power Draw: +12V: 15mA, -12V: 15mA

• Inputs: 2 independent inputs

• Outputs: 3 buffered outputs per section
