ALM Pamela's Disco

Pamela’s Disco syncs Eurorack modular and other compatible devices to the ‘Master’ Tempo of a PRO DJ-LINK™ Network. This enables syncing your modular to your decks for unique hybrid DJ sets. The Disco listens to a PRO DJ-LINK network via an Ethernet connection and converts the ’Master’ tempo information to standardmodular clock signals. Easily sync Pamela’s PROWorkout and other devices with your mix. The Disco provides standard ’DIN Sync’ style clocking outputs as well as beat and bar trigger outputs. LEDs show connection, status and tempo. A ’Resync’ button provides manual latched beat synced control of the outputted clock. Compact and easy to set up, the Disco opens up new performance possibilities - mix, overdub, spinback and scratch, all locked in time with your modular

FEATURE LIST

→ Sync your modular up to your decks!

→ Converts tempo & clock from PRO DJ LINK™ network to modular clock outputs.

→ Easy ’just works’ setup with no configuration.

→ Standard ’DIN Sync’ style x24 & Run analog clock out for tight reliable syncing.

→ Additional Beat & Bar trigger outputs.

→ Automatic start and stopping detection.

→ LED beat and connection status indication.

→ Resync button for cueing, manual and fine control.

→ Pairs great with Pamela’s PROWorkout for endless synced clocking, patterns andmodulation (Use Pams expanders for MIDI Clock output).

→ Skiff friendly with reverse power protection.

→ 2 Year Warranty.

→ Made in England.

TECHNICAL SPECIFICATIONS

→ Supply: +12V 90mA / -12V 0mA

→ Size: 4HP

→ Depth: 32mm
