Intellijel Atlx 1U Atlantix Expander

Intellijel Atlx 1U Atlantix Expander

Regular price €56,00
Sale price Regular price

Product details

Main features

  • Oscillator outputssine, triangle, saw and square for A and B, PWM on A, sub square on A
  • Filter outputsseparate lowpass, highpass, bandpass and Phazor taps
  • Ring modulatorX and Y inputs with a RING output
  • Expansion16 extra jacks for the Atlantix synth voice

Overview

The Intellijel Atlx 1U is an output expander for the Intellijel Atlantix, a dual-oscillator subtractive analogue synth voice. It works only with Atlantix. It suits Atlantix owners who want more patch points for self-patching, more complex routing and connections to the rest of their system, and who would rather spend 1U row space than 3U space. It has the same functions as the 3U Atlx.

  • 16 extra jacks: 14 dedicated outputs plus a ring modulator
  • Oscillator A and B taps: sine, triangle, saw and square outputs, with PWM on oscillator A and a sub square output on A only
  • Filter taps: separate lowpass, highpass, bandpass and Phazor outputs
  • Ring modulator: X and Y inputs with a RING output
  • Passive design: draws no current from your power supply
  • 1U format: a 20 HP tile in Intellijel 1U format, connected to Atlantix with the included cable

Breaking out the individual waveforms and filter responses lets the semi-modular Atlantix behave more like a fully modular voice. With the separate oscillator outputs you get more flexible FM and cross-modulation, and the filter taps give you the whole Atlantix filter section rather than a single response. The ring modulator can process signals from the Atlantix or from other modules in the case.

Specifications· 10 details

Format

Format
1U (Intellijel format)
Width
20 HP

Inputs & outputs

Total jacks
16
Oscillator A outputs
Sine, Triangle, Saw, Square (PWM), Sub Square
Oscillator B outputs
Sine, Triangle, Saw, Square
Filter outputs
Lowpass, Highpass, Bandpass, Phazor
Ring modulator
X In, Y In, RING Out

Power

Power
Passive, no current draw

General

Functions
Effects, Utility, and I/O
Height
1U
