Befaco Pony VCO – DIY Kit

Befaco Pony VCO – DIY Kit

Regular price €164,00
Sale price Regular price

Product details

Main features

  • Thru-zero FManalog thru-zero core based on a Sound Semiconductor IC
  • WavefolderTimbre control for wavefolding, plus PWM and sync
  • Built-in VCAdedicated VCA for level control inside the module
  • LFO rangerange selector reaches LFO rates, with octave and waveform selectors

Overview

The Befaco Pony VCO DIY Kit is the kit version of Befaco's Pony VCO, a fully analog thru-zero oscillator with a wavefolder and a dedicated VCA in a 4HP Eurorack module. Befaco describes it as a pre-soldered DIY kit and marks it as beginner grade. It suits patchers who want a compact sound source that can also run as an LFO and who are comfortable finishing a kit build.

  • Thru-zero FM: pitch responds to both positive and negative voltage. When FM pushes below zero, the core keeps oscillating with inverted phase, which gives timbres a standard VCO cannot produce.
  • Wavefolder: the Timbre control sets how hard the waveform is folded and has its own CV input.
  • Built-in VCA: patch an envelope or LFO into the VCA input to shape level without an external VCA.
  • Selectable waveforms: sine, triangle, sawtooth and square, plus PWM and sync.
  • Four range modes: Full, Octave, Semitone and LFO, with a separate octave selector.

The oscillator core uses a Sound Semiconductor IC, which Befaco credits for the module's stability and tuning. The combination of thru-zero FM, folding and an onboard VCA means one Pony can work as a complete voice, while LFO mode makes it useful as a modulation source in small cases. At 30 mm deep including the power connector, it also fits shallow skiff cases. The front panel is heat-treated aluminium.

Specifications· 19 details

Format

Format
Eurorack 3U
Width
4HP
Depth
30 mm (including power connector)
Front panel
Heat-treated aluminium
Befaco reference
DIY040

Inputs & outputs

CV inputs
Pitch (1V/oct), FM, Timbre, VCA
Sync input
Yes
Output
VCO out

Controls

Range modes
Full, Octave, Semitone, LFO
Waveforms
Sine, triangle, sawtooth, square
Timbre
Wavefolder amount

Power

Power draw +12V
32 mA

General

DIY
Yes
Functions
Modulation
Height
3U
Synthesis method
Polyphony
Synthesizer form factor
Control voltage or gate connectivity
,

About the brand

Befaco

Barcelona-based maker of open-source Eurorack modules, sold assembled or as DIY kits. Known for experimental voices such as Oneiroi, hands-on build workshops and designs released under a Creative Commons licence.
Origin
ES
Founded
2010
Products
127
