IK Multimedia iRig Pro I/O

The ultra-compact professional audio/MIDI interface for all your gear

Now record with any of your gear on the go, and monitor in real time with any compatible device! That’s iRig Pro I/O, the ultra-compact professional quality audio and MIDI in/out for your mobile recording life!

iRig Pro I/O is the next generation of the iRig Pro — the first mobile interface for connecting all of your studio gear to your iPhone, iPad, Mac, PC or Android device to play and record on the go.

iRig Pro I/O is a pocket-sized full-featured audio and MIDI interface that gives you 24-bit/96kHz recording studio quality sound everywhere you go with a few additional essential features for mobile recording.

First, iRig Pro I/O is designed to be “plug and play” easy to use with all of your gear — studio mics, vocal performance mics, guitars, basses, keyboards — whatever it is, iRig Pro I/O can handle it.

Second, iRig Pro I/O features a new 1/8" stereo headphone out with preamp and level control, making it compatible with even the most recent iOS devices. Plus, when used with the optional DC power supply, iRig Pro I/O will charge your iPhone or iPad while in use for unlimited playing and recording time. iRig Pro I/O also features a new MIDI Out jack that gives you even more flexibility and control over your outboard MIDI gear.

Bottom line: iRig Pro I/O is the most versatile and intuitive “all in one” mobile interface available.

• Combination input XLR and 6.3 mm jack for microphone, line and instrument signals
• High-quality preamplifier with adjustable gain
• High-quality ADDA conversion with up to 24 bit / 96 kHz
• Adjustable stereo headphone output
• MIDI input and output
• Power supply via USB, 2x AA batteries or optional mains adapter (not included)
• Headphone output: 3.5 mm stereo jack unbalanced, 100 mW at 50 Ohm
• MIDI input and output: 2x 2.5 mm mono jack
• Power supply connection 5.4 V DC (optional power supply: Article no. 417705, not included)
• Device connection Mini-DIN
• Dimensions: 43 x 127 x 37 mm
• Weight: 120 g (without batteries)

Microphone input:

• XLR balanced
• +48V +/-4V Phantom powering
• 40 dB gain
• Impedance 1.6 kOhm
• Frequency range: 20-20000 Hz +/-1.5 dB
• Noise level -103 dB(A)
• -97 dB RMS

Instrument input:

• 6.3 mm jack, unbalanced
• 27 dB gain
• Impedance 1 MOhm
• Frequency range: 20-20000 Hz +/-1.5 dB
• Noise level -103 dB(A)
• -97 dB RMS

Includes:

• iRig Pro I/O Audio MIDI Interface
• Lightning to mini-DIN adapter cable 0.6 m
• USB to Mini-DIN adapter cable 0.6 m
• 2x 2.5 mm jack MIDI adapter cable 1.6 m
• 2x 1.5 V AA battery
• Comprehensive software package AmpliTube 4 and AmpliTube 5 SE as download via manufacturer/app store
